Technical parameter
Dimensions: 1340mm × 550mm × 1800mm (l × w× h);
Power supply: Single phase, AC220V/50Hz;
Working temperature: -40 ° C ~ +50 ° C.
Weight: About 80kg
Product description
This Electric Car Charging Pile Board Teaching Trainer Automotive Educational Equipment Automotive Equipment consists of a real and operable plug-in electric car charging system. It can demonstrate the three-phase full-bridge rectification principle and working process, including three-phase charging pile card swiping principle demonstration, three-phase full-bridge rectification process demonstration, charging system handshake signal and charging process demonstration, etc.
Product composition
1. Three-phase AC charging pile module;
2. Three-phase full-bridge rectifying car charger module;
3. Charging gun module;
4. Power supply cable: connect to the power supply
Training courses
1. To understand the structure and principle of the electric car charging system;
2. To understand the control process and methods of the electric car charging system;
3. To understand how to charge the battery pack
4. Demonstrates the principle and working process of three-phase full-bridge rectification;
5. Demonstrate the handshake signal and process of charging system.
Specification
| item | value |
| Place of Origin | INDIA,ROORKEE |
| Brand Name | METLOR |
| Model Number | MATL-D0003 |
| Place of Origin | ROORKEE, INDIA |
| Application | Training Center |
| Function | Student Learning |
| MOQ | 1 Set |
| Usage | Electric vehicle training equipment |
| Size | 1340mmX550mmX1800mm |
| Weight | About 80kg |
| Power supply | AC220V/50Hz |
| Warranty | 12 Months |
| Package | Wooden Box |
