Engine model:
Toyota Vios engine with transmission
The trainer uses dissectioned gasoline engine, with manual transmission. Different parts are marked with different colors for
students’ better understanding of structure and working principles of engine and transmission.
Connected to 220V power supply, the students can easily understand the power transmission system’s structure and working processes
4 movable casters for easy operation.
Simple and clear design of cutaway structure.
Offer students a opportunity to improve hands on practice. It is beneficial for engine repair and maintenance
Gasoline Engine
FF type manual transmission system structure
Composition DOHC Engine
4 cylinders
Manual forward 5 & rear 1
Clutch
AC 220V/180W Motor
Engine speed controller
Emergency Switch
Safety Fuse light
Steel frame w/ heat treatment painting
