Main features
1.Test stand for holding prepared single cylinder engines (two-stroke and four-stroke) with a maximum power output of 3kW
2. The engine modules can be tested on this stand is MATL-T007, MATL-T010
3.The engine modules can be connected to brake unit by V-belt drive or elastic coupling
4.Brake speed can be continuously adjusted
5.Measurement and display of temperatures (oil, fuel, air), engine load, speed, fuel consumption, air intake quantity, oil
pressure
6.Fuel supply tanks for 2 different fuels: gasoline, diesel.
Technical parameter
1. Dimension: Control stand: 1100×660*1800mm.
Test bench: 1200x500x1100mm
2.Measuring ranges:
-Ambient temperature：0-100°C
– Fuel temperature：0-100°C
– Air consumption：30-333L/min
– Fuel consumption：0-50cm3/min
3.Power supply：three-phase 380V/AC, single-phase 220V/AC;
