(The engine module not included)
Main features
1.Asynchronous motor with regenerative feedback unit work as the brake unit for generating the engine load;
2. Can test engine module MATL-T012;
3. Power transmission from test engine to brake unit by elastic coupling;
4. Quietening vessel for intake air;
5. Potentiometer for continuous adjustment of braking torque and speed;
6.Torque, air temperature, air intake quantity, negative intake pressure, speed, fuel consumption, fuel temperature can be measured and displayed;
7.Data measured and displayed for the engine tested: Exhaust gas temperature and cooling water temperatures
Technical parameter
1.Dimension: Control stand: 1100 x 600 x1800mm.
Test bench: 1300 x 900 x1300mm.
2.Power supply：three-phase AC 380V, single-phase AC 220V;
3.Asynchronous motor as brake unit:- Power output: approx. 7.5kW
4.Regenerative feedback unit: 13kW
5.Measuring ranges
– Torque: -50-50Nm
– Temperatures: 0-900°C
– Speed: 0-5000rpm
– Fuel consumption: 50cm³/min
– Air consumption: 0-690L/h
